iSurfer Part 2: From Touch Input to GPU Silicon — The Equation Parser & On-the-Fly GLSL Shader Compiler

In Part 1 of the iSurfer series, we saw why rendering implicit algebraic surfaces $f(x, y, z) = 0$ with sharp singularities requires casting continuous per-pixel rays inside an OpenGL ES 2.0 fragment shader rather than generating polygon meshes with Marching Cubes.

That architectural choice immediately confronts a hard hardware constraint: OpenGL ES 2.0 fragment shaders run compiled machine code on the GPU, but the equation $f(x, y, z) = 0$ is typed by the user at runtime.

How do you let a user type an arbitrary equation like:

textCopy
4(x^2 + y^2 - z^2) + 16xyz - 1

and execute it tens of millions of times per second on a mobile GPU?

---

1. Why a Shader Bytecode Interpreter Fails on Mobile GPUs#

When engineers first encounter the problem of evaluating user-defined formulas on a GPU, their first instinct is often to write one static fragment shader containing a stack-based virtual machine (RPN / Postfix bytecode interpreter):

1. Parse the user's string on the CPU into an array of opcodes (OP_PUSH_X, OP_CONST 2, OP_POW, OP_ADD, ...).
2. Upload the opcode array as a uniform int uProgram[64] buffer.
3. Run a for loop with a switch / if-else dispatch ladder inside float evaluate(vec3 p) on the GPU.

We benchmarked this approach early on, and it is roughly $25\times$ to $40\times$ slower than native GLSL—dropping frame rates from 30+ FPS to under 1 FPS. Why?

• Inner-Loop Amplification: For a single pixel, the raymarcher + root refiner evaluates $f(\mathbf{p})$ between 24 and 64 times (stepping along the ray to isolate a sign change, then running Bisection/Newton iterations, then evaluating $\nabla f(\mathbf{p})$ for lighting). If your RPN interpreter loop takes 30 instructions per evaluation, a single pixel executes ~2,000 dynamic loop iterations and branches!
• SIMD Tile Divergence & Register Spilling: Mobile GPUs (like the PowerVR SGX series in early iPhones) execute fragments in lockstep SIMD warps across tiles. Maintaining a mutable evaluation float stack[16] array with dynamic indexing (stack[sp++]) prevents the shader compiler from keeping variables in hardware registers, forcing local memory spills and destroying ALU occupancy.
• Zero Constant Folding or Instruction Scheduling: A bytecode interpreter cannot fuse multiply-adds (FFMA) or hoist ray-invariant terms out of the loop.

The Breakthrough: Using glCompileShader as a Live JIT Compiler#

OpenGL ES 2.0 ships with a full optimizing GLSL compiler built directly into the iOS graphics driver (glShaderSource $\to$ glCompileShader $\to$ glLinkProgram).

• Equation edits happen at human speed (once every few seconds when the user finishes typing a formula).
• Camera rotations, pinch-zooms, and parameter slider animations happen at 60 Hz (every 16.6 ms).

By translating the user's equation into specialized, branch-free GLSL source code on the CPU and invoking glCompileShader on the fly whenever the equation string changes, the iOS driver compiles our exact polynomial down to native PowerVR hardware instructions (FMUL, FADD, FFMA) in ~8–15 milliseconds—and every frame thereafter runs at full hardware speed!

---

2. Stage 1: Lexical Analysis & Human Math Normalization#

Mathematicians and students do not write formulas in strict C/GLSL syntax. If someone types 2x^2 + 3xy - z(1 - z) into a raw GLSL shader, compilation fails for three separate reasons:

1. Implicit Multiplication: 2x, 3xy, and z(1 - z) omit the * operator.
2. Caret Exponentiation: In C and GLSL, ^ is the bitwise XOR operator, not exponentiation!
3. Strict Integer-Float Typing in GLSL ES 1.00: In GLSL ES (#version 100), writing float val = 2 * p.x + 1; is a fatal compile error ('*' : wrong operand types - no operation '*' exists that takes a left-hand operand of type 'const int' and a right operand of type 'highp float'). Every numeric literal must be emitted with a decimal point (2.0, 1.0).

Our tokenizer scans the input stream into typed tokens (number, variable, operator, function, lparen, rparen) and applies two normalization passes:

• Multi-Variable Splitting & Implicit Multiplication Insertion: Whenever a number, variable, or rparen token is immediately followed by a variable, function, or lparen token without an intervening operator, the lexer synthesizes an explicit { type: 'operator', value: '*' } token:
  • 16xyz $\longrightarrow$ 16.0 * x * y * z
  • (x^2 + y^2)(y^2 + z^2) $\longrightarrow$ (x^2 + y^2) * (y^2 + z^2)
• IEEE Float Literal Formatting: Every integer constant N is formatted as N.0 in the emitted GLSL (except when inspected as an integer exponent by the AST power expander).

---

3. Stage 2: Recursive-Descent AST Construction & Degree Classification#

From the normalized token stream, a Recursive-Descent Parser constructs a typed Abstract Syntax Tree (ASTNode) respecting standard mathematical operator precedence and associativity:

1. parseExpression(): Left-associative binary addition and subtraction (+, -).
2. parseTerm(): Left-associative binary multiplication and division (*, /).
3. parsePower(): Right-associative exponentiation (^), so a ^ b ^ c parses as a ^ (b ^ c).
4. parseUnary(): Prefix unary operators (-x, +x).
5. parsePrimary(): Parenthesized sub-expressions (...), function calls (sin, cos, sqrt, pow), variables (x, y, z, parameters a, b, c, d, time t), and numeric literals.

typescriptCopy
export type ASTNodeType = 'number' | 'variable' | 'binary' | 'unary' | 'function';

export interface ASTNode {
  type: ASTNodeType;
  value?: number | string;
  operator?: string;
  left?: ASTNode;
  right?: ASTNode;
  argument?: ASTNode;
  args?: ASTNode[];
}

Once the AST is built, we traverse it with calculateDegree(ast) before generating any shader code:

• Variables X, Y, Z have degree $1$; constants and uniform parameters (A, B, C, D) have degree $0$.
• Addition/subtraction takes $\max(\deg(L), \deg(R))$.
• Multiplication takes $\deg(L) + \deg(R)$.
• Exponentiation base ^ exp with a non-negative integer constant exp takes $\deg(\text{base}) \times \text{exp}$.

Knowing the total degree $d$ (e.g., $d=2$ quadric, $d=3$ cubic, $d=4$ quartic, $d=6$ sextic) allows the shader compiler to select the optimal root-finding strategy and step count automatically!

---

4. Stage 3: Why pow(x, n) Breaks Negative Coordinates—and How AST Power Unrolling Fixes It#

One of the most subtle traps in GPU mathematical rendering involves translating x^2 or (x + y)^3 into GLSL.

If you naively translate A ^ B into GLSL's built-in pow(A, B):

1. The Negative-Base NaN Bug: According to the OpenGL ES Shading Language specification (Section 8.2, Exponential Functions), pow(x, y) results are undefined if $x < 0$! Why? Because GPUs implement pow(x, y) in hardware using the Special Function Unit (SFU) identity: $\text{pow}(x, y) = 2^{y \cdot \log_2(x)}$ Whenever a pixel ray passes through negative coordinates ($x < 0$, which is 7 out of the 8 octants of $\mathbb{R}^3$!), $\log_2(x)$ evaluates to NaN. As a result, translating x^2 + y^2 + z^2 - 1 into pow(p.x, 2.0) + pow(p.y, 2.0) + pow(p.z, 2.0) - 1.0 causes 7/8ths of the sphere to vanish into NaN black pixels on mobile GPUs!
2. SFU Throughput Bottleneck: Even if you wrap the base in abs(x) for even powers, hardware transcendental instructions (LG2 + MUL + EX2) have $4\times$ to $8\times$ lower throughput than standard floating-point multipliers (FMUL).

Balanced Binary Multiplication Tree Unrolling#

To guarantee both mathematical correctness across all 8 octants of $\mathbb{R}^3$ and maximum ALU throughput, our AST code generator intercepts every ^ node with an integer exponent $n \in \mathbb{Z}$ and expands it into a balanced tree of pure multiplications:

typescriptCopy
function expandIntegerPower(baseStr: string, exp: number): string {
  if (exp === 0) return '1.0';
  if (exp === 1) return baseStr;
  if (exp === 2) return `((${baseStr}) * (${baseStr}))`;
  if (exp === 3) return `((${baseStr}) * (${baseStr}) * (${baseStr}))`;
  if (exp === 4) {
    // Balanced tree: (b*b) * (b*b) -> only 2 dependent multiply depths!
    return `(((${baseStr}) * (${baseStr})) * ((${baseStr}) * (${baseStr})))`;
  }
  if (exp === 5) {
    return `((((${baseStr}) * (${baseStr})) * ((${baseStr}) * (${baseStr}))) * (${baseStr}))`;
  }
  if (exp === 6) {
    return `(((${baseStr}) * (${baseStr})) * ((${baseStr}) * (${baseStr})) * ((${baseStr}) * (${baseStr})))`;
  }
  if (exp < 0 && exp >= -6) {
    return `(1.0 / ${expandIntegerPower(baseStr, -exp)})`;
  }
  return `safe_pow(${baseStr}, ${formatGlslFloat(exp)})`;
}

And for non-integer or variable exponents (such as $x^{2/3}$), we emit a sign-preserving safe_pow(base, exp) helper in the shader preamble that handles negative bases cleanly without producing NaN.

---

5. Stage 4: Symbolic Partial Differentiation on the AST#

To shade the surface with Blinn-Phong or PBR lighting—and to run Newton-Raphson root refinement along the ray—we need the surface gradient $\nabla f(x, y, z) = \left(\frac{\partial f}{\partial x}, \frac{\partial f}{\partial y}, \frac{\partial f}{\partial z}\right)$.

Because the equation is already represented as an in-memory ASTNode tree, we can differentiate the AST symbolically with respect to any variable $v \in \{X, Y, Z\}$ in a single recursive pass (differentiateAST(node, v)):

• Constant / Other Variable Rule: $\frac{\partial c}{\partial x} = 0$, $\frac{\partial y}{\partial x} = 0$, $\frac{\partial x}{\partial x} = 1$.
• Sum & Difference Rule: $\frac{\partial (u \pm w)}{\partial x} = \frac{\partial u}{\partial x} \pm \frac{\partial w}{\partial x}$.
• Product Rule: $\frac{\partial (u \cdot w)}{\partial x} = \frac{\partial u}{\partial x} \cdot w + u \cdot \frac{\partial w}{\partial x}$.
• Power & Chain Rule: $\frac{\partial (u^n)}{\partial x} = n \cdot u^{n-1} \cdot \frac{\partial u}{\partial x}$.

Running a quick algebraic simplification pass (pruning 0 * expr $\to$ 0, 1 * expr $\to$ expr, and expr + 0 $\to$ expr) produces a compact, exact analytical gradient function vec3 grad_f(vec3 p) right inside the generated shader! (For complex transcendental expressions in SurfZar, we also pair this with a symmetric 4-point tetrahedral finite-difference stencil to keep instruction counts bounded.)

---

6. Stage 5: Real-Time On-Device Shader Compilation & Hot-Swapping#

Once the AST emitter produces the GLSL strings for f(vec3 p) and grad_f(vec3 p), it injects them into the master fragment shader template (#define USER_FUNCTION ...) and triggers an immediate GPU recompile on the active EAGLContext (on iOS) or WebGL2RenderingContext (in SurfZar):

cCopy
// Objective-C / OpenGL ES 2.0 on-the-fly compilation pipeline
GLuint fragShader = glCreateShader(GL_FRAGMENT_SHADER);
const GLchar *sourcePtr = (const GLchar *)[generatedGLSLSource UTF8String];
glShaderSource(fragShader, 1, &sourcePtr, NULL);
glCompileShader(fragShader);

GLint compiled = GL_FALSE;
glGetShaderiv(fragShader, GL_COMPILE_STATUS, &compiled);
if (compiled == GL_TRUE) {
    GLuint newProgram = glCreateProgram();
    glAttachShader(newProgram, cachedVertexShader);
    glAttachShader(newProgram, fragShader);
    glLinkProgram(newProgram);

    // Atomic hot-swap: keep previous valid shader running if user is mid-typing!
    glDeleteProgram(activeProgram);
    activeProgram = newProgram;
    [self rebindUniformLocations:activeProgram];
}
glDeleteShader(fragShader);

Notice the Atomic Hot-Swap pattern: while a user is mid-typing an incomplete expression like x^2 + y^2 -, the parser or compiler detects the incomplete syntax and keeps the previous compiled GLuint activeProgram bound, displaying a non-intrusive syntax indicator in the HUD. The instant the user types the final character 1, the new shader compiles in ~10 ms and swaps in on the very next CADisplayLink / requestAnimationFrame vsync tick!

---

Up Next in Part 3#

Now that our user's equation is compiled into native GPU machine instructions inside float f(vec3 p), how does the fragment shader actually intersect each pixel ray with the surface, isolate the closest root among up to 6+ intersections, refine it without diverging at singularities, and shade both sides of the manifold?

Read iSurfer Part 3: Inside the OpenGL ES 2.0 Fragment Shader Ray Tracer — Root Isolation, Safeguarded Newton-Bisection & Two-Sided Shading.
