LSystemTS: Rendering Recursive Lindenmayer Fractals & Space-Filling Curves in TypeScript

In my previous post on Deploying My First TypeScript Library, I walked through packaging and publishing turtle-ts to the npm registry so I would have a clean 2D Turtle Graphics foundation in TypeScript.

Two weeks later, I completed the second half of that experiment: lsystemts (daniazar/lsystemts)—a Lindenmayer System (L-System) grammar evaluator that consumes turtle-ts to generate self-similar fractals and space-filling curves in the browser.

---

What is an L-System Grammar?#

Introduced in 1968 by biologist Aristid Lindenmayer to model cellular and plant growth, a deterministic context-free L-System is a formal grammar $G = (V, \omega, P)$ defined by:

1. Alphabet ($V$): Terminal drawing symbols (F = draw forward, f = move forward with pen up, + = turn right by $\theta$, - = turn left by $\theta$) and non-terminal variables (X, Y).
2. Axiom ($\omega$): The initial starting string at iteration $0$.
3. Production Rules ($P$): Rewrite rules (Rule.ts) that map each symbol to a replacement string at every recursion step.

---

Why Depth-First Recursion Beats String Expansion#

A naive L-System implementation rewrites the entire string in memory at each iteration ($S_0 \rightarrow S_1 \rightarrow \dots \rightarrow S_n$) before drawing. However, because production rules expand exponentially—for example, the Sierpinski rule X → XF+XF-XF-XF+XF multiplies string length by $5\times$ per step—allocating the full expanded string at higher iteration depths quickly wastes megabytes of heap memory.

In lsystemts, src/LSystem.ts avoids materializing intermediate strings altogether by evaluating the production rules recursively on the fly via depth-first traversal (iterateAxiom):

typescriptCopy
import { Turtle } from "turtle-ts";
import { Options } from "./Options";
import { Rule } from "./Rule";

export class LSystem {
  private _axiom: string;
  private _rules: Record<string, Rule> = {};
  protected _options: Options;
  protected _turtle: Turtle;

  public constructor(axiom: string, rules: Rule[], options: Options, turtle: Turtle) {
    this._axiom = axiom;
    this._options = options;
    for (const rule of rules) {
      this._rules[rule.letter] = rule;
    }
    this._turtle = turtle;
  }

  public start() {
    this._turtle.setColor(this._options.color);
    this.iterateAxiom(this._axiom, this._options.iterations);
  }

  public iterateAxiom(axiom: string, iterations: number) {
    if (iterations === 0) return;
    for (const c of axiom) {
      switch (c) {
        case '+':
          this._turtle.right(this._options.angle);
          break;
        case '-':
          this._turtle.left(this._options.angle);
          break;
        case 'F':
          this._turtle.forward(this._options.length);
          break;
        case 'f':
          this._turtle.penUp();
          this._turtle.forward(this._options.length);
          this._turtle.penDown();
          break;
        default: {
          const rule = this._rules[c.toUpperCase()];
          if (rule) {
            this.iterateAxiom(rule.axiom, iterations - 1);
          }
        }
      }
    }
  }
}

Because iterateAxiom only holds the current call-stack frames (bounded by iterations, typically $3 \le n \le 8$), memory usage stays $O(n)$ regardless of how many thousands of line segments are drawn.

---

Built-In Fractal Presets (src/Examples.ts)#

To make testing and visual experimentation immediate, lsystemts includes a static Examples catalog (src/Examples.ts) defining classic fractals and space-filling curves:

Check out the full source code on GitHub at github.com/daniazar/lsystemts.
