SurfZar Deep-Dive: Writing a Zero-Dependency Galois Field GF(256) Reed-Solomon QR Encoder & Compact URL Serializer

One of the core design principles of SurfZar is that it operates with zero backend database. When a professor, researcher, or digital artist crafts an algebraic surface with custom parameters $a, b, c, d$, dual-sided PBR textures, custom camera angles, cross-section clipping planes, and a 10-second multi-track keyframe animation, they should be able to share that exact studio state via a single self-contained URL or QR code that will still work 20 years from now.

Achieving that required solving two engineering problems in src/lib/UrlState.ts and src/lib/QrCodeGenerator.ts:

1. Compact Delta-Encoded State Serialization (UrlState.ts): Compressing 40+ studio state fields and keyframe arrays so the URL fits comfortably inside QR Code Version 1–10 byte limits.
2. A Zero-Dependency ISO/IEC 18004 QR Code Generator (QrCodeGenerator.ts): Implementing Galois Field $\text{GF}(2^8)$ polynomial arithmetic, Reed-Solomon Error Correction, and ISO Mask Penalty evaluation from scratch in ~350 lines of pure TypeScript.

1. Compact Key-Mapped & Delta-Pruned URL Serialization (UrlState.ts)#

If you naively JSON.stringify() a Zustand store containing camera vectors, material presets, and animation tracks and Base64-encode it, even a simple sphere produces an 800+ character URL—exceeding the capacity of compact QR codes and getting truncated by messaging apps.

In src/lib/UrlState.ts, serializeStateToUrl() applies a three-stage compression pipeline:

1. Default-Delta Pruning: Any setting that matches the studio's default state (e.g., roughnessA === 0.2, boundingShape === 'sphere', shellThickness === 0) is omitted completely from the payload.
2. Float Quantization & Short-Key Dictionary (CompactSharePayload): Floating-point camera coordinates [x, y, z] and keyframe timestamps are rounded to 3 decimal places (Math.round(v * 1000) / 1000), and verbose property names are mapped to 1-to-3 character keys (eq, a, b, c, d, m, cA, cB, bs, cam, kfs).
3. UTF-8 Safe URL-Base64 Encoding (toUrlSafeBase64): The resulting compact JSON string is UTF-8 byte-encoded and mapped to RFC 4648 URL-safe Base64 (+ $\to$ -, / $\to$ _, stripping = padding), producing clean #share=... hashes under 180 characters.

2. Writing an ISO/IEC 18004 QR Code Generator from First Principles (QrCodeGenerator.ts)#

Ironically, many mathematical apps that render 3D surfaces on the GPU pull in 50 KB+ of legacy CommonJS <canvas> dependencies just to draw a 2D QR code modal.

Because QR codes are themselves a beautiful application of abstract algebra over finite fields, I wrote src/lib/QrCodeGenerator.ts from scratch in pure TypeScript—producing crisp, resolution-independent <svg> markup with zero external packages.

Step 1: Galois Field $\text{GF}(2^8)$ Log/Antilog Lookup Tables#

Reed-Solomon error correction operates over the finite field $\text{GF}(256)$ (also written $\mathbb{F}_{2^8}$), where each byte $b \in [0, 255]$ represents a polynomial of degree $\le 7$ with binary coefficients in $\mathbb{F}_2[x]$ modulo the QR specification's irreducible primitive polynomial:

$p(x) = x^8 + x^4 + x^3 + x^2 + 1 \quad (\text{hexadecimal } \mathtt{0x11d} = 285)$

In $\text{GF}(2^8)$:

• Addition and subtraction are both bitwise XOR (^), because $-1 \equiv +1 \pmod 2$.
• Multiplication (gfMul) modulo $p(x)$ is accelerated to $O(1)$ by precomputing the powers of the generator element $\alpha = 2$ into GF_EXP (antilog) and GF_LOG tables at module initialization:

typescriptCopy
// Galois Field GF(256) with primitive polynomial 0x11d (x^8 + x^4 + x^3 + x^2 + 1)
const GF_EXP = new Uint8Array(512);
const GF_LOG = new Uint8Array(256);

(function initGF() {
  let x = 1;
  for (let i = 0; i < 255; i++) {
    GF_EXP[i] = x;
    GF_LOG[x] = i;
    x <<= 1;
    if (x & 0x100) x ^= 0x11d; // Reduce modulo p(x)
  }
  for (let i = 255; i < 512; i++) {
    GF_EXP[i] = GF_EXP[i - 255];
  }
})();

function gfMul(a: number, b: number): number {
  if (a === 0 || b === 0) return 0;
  return GF_EXP[GF_LOG[a] + GF_LOG[b]];
}

Step 2: Reed-Solomon Generator Polynomial & Synthetic Division#

To generate $k$ error-correction codewords (eccLen), we construct the Reed-Solomon generator polynomial $g(x)$ whose roots are $\alpha^0, \alpha^1, \dots, \alpha^{k-1}$:

$g(x) = \prod_{i=0}^{k-1} \left(x - \alpha^i\right)$

and compute the remainder of the message polynomial $M(x) \cdot x^k$ divided by $g(x)$ using polynomial synthetic division over $\text{GF}(256)$:

typescriptCopy
function getGeneratorPoly(degree: number): Uint8Array {
  let g: Uint8Array = new Uint8Array([1]);
  for (let i = 0; i < degree; i++) {
    g = polyMul(g, new Uint8Array([1, GF_EXP[i]]));
  }
  return g;
}

function calculateEcc(data: Uint8Array, eccLen: number): Uint8Array {
  const gen = getGeneratorPoly(eccLen);
  const msg = new Uint8Array(data.length + eccLen);
  msg.set(data);

  for (let i = 0; i < data.length; i++) {
    const coef = msg[i];
    if (coef !== 0) {
      for (let j = 0; j < gen.length; j++) {
        msg[i + j] ^= gfMul(gen[j], coef);
      }
    }
  }
  return msg.slice(data.length);
}

Step 3: Multi-Block Interleaving, Zig-Zag Placement & 8-Mask Penalty Scoring#

For larger URLs (QR Versions 5–10), the payload is split across multiple Reed-Solomon blocks whose data and parity bytes are interleaved so a localized smudge on the QR code distributes bit errors evenly across blocks.

Finally, QrCodeGenerator.ts:

1. Places the three $7 \times 7$ Finder Patterns, Timing Strips, Dark Module, and version-specific Alignment Patterns on the $N \times N$ matrix while marking them in a reserved mask.
2. Snakes the interleaved bitstream upward and downward in 2-column Zig-Zag strips from the bottom-right corner (skipping vertical timing column $x = 6$).
3. Evaluates all 8 ISO data masks (mask 0 through mask 7) against the four ISO/IEC 18004 penalty rules (runs of $\ge 5$ identical bits, $2 \times 2$ solid blocks, false finder-like 1:1:3:1:1 patterns, and dark/light balance ratio), selects the mask with the lowest penalty score, writes the BCH-encoded 15-bit format string, and emits a single compact <svg><path d="..."/></svg> element!
