WebScreen: Declarative Headless Chrome Screenshot & DOM Capture Automation

Whether you are generating visual regression snapshots across environments, archiving marketing pages, or extracting specific UI widgets for documentation, manually taking and cropping browser screenshots quickly becomes tedious.

To automate this workflow, I built WebScreen (daniazar/webscreen)—a declarative, JSON-driven screenshot engine written in TypeScript on top of Headless Chrome and the Puppeteer API.

Declarative Capture via url.json#

Instead of writing custom imperative Puppeteer scripts every time you need to capture a new site or component, WebScreen reads a declarative url.json manifest where each entry specifies:

• Full-Page or Viewport Capture (fullPage, capturePage, custom viewport.width $\times$ viewport.height).
• Targeted DOM Element Crops (elements): An array of CSS selectors (.class or #id) that WebScreen locates in the live DOM, computes bounding boxes for, and exports as isolated image files.
• Output Format (extension): Supports lossless png or compressed jpeg output.

jsonCopy
[
  {
    "url": "https://github.com/",
    "name": "github",
    "fullPage": true,
    "capturePage": true,
    "elements": [
      ".home-hero-signup"
    ],
    "extension": "jpeg"
  },
  {
    "url": "https://google.com/",
    "viewport": {
      "width": 300,
      "height": 400
    },
    "capturePage": true,
    "elements": [
      ".content",
      "#hplogo"
    ]
  }
]

How the Capture Pipeline Works#

For each target in url.json:

1. Viewport Configuration: If a custom viewport is defined (e.g., 300x400 to simulate a mobile device), WebScreen resizes the headless browser tab before navigation so responsive media queries trigger accurately.
2. Page-Level Capture: When capturePage: true is enabled, it captures either the visible viewport or the stitched fullPage scroll height.
3. Sub-Element Isolation: It iterates through the elements array, queries each CSS selector via page.$(selector), and renders an exact bounding-box screenshot of that DOM node (github_0.jpeg, google_1.png, etc.).

The repository and documentation are available on GitHub at github.com/daniazar/webscreen.
